- Managed L2 Web-based management
- Quality of Service (QoS) support
- Basic switching RJ-45 Ethernet ports quantity: 8
- MAC address table: 4000 entries Switching capacity: 16 Gbit/s
- Power supply included
HARDWARE FEATURES
Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p
Interface:
– 8 10/100/1000 Mbps RJ45 Ports
– AUTO Negotiation/AUTO MDI/MDIX
Network Media: 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
– 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
– 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity: Fanless
Power Supply: External Power Adapter(Output: 9 VDC/ 0.6 A)
Dimensions ( W x D x H ): 6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm)
Max Power Consumption: 3.68 W (220 V/ 50 Hz)
Max Heat Dissipation: 12.55 BTU/h
PERFORMANCE
Switching Capacity: 16 Gbps
Packet Forwarding Rate: 11.9 Mpps
MAC Address: Table 4 K
Packet Buffer: Memory 1.5 Mb
Jumbo Frame: 16 KB
