- 5× 10/100/1000 Mbps RJ45 ports
- With four PoE+ ports, transfers data and power on one single cable
- Works with IEEE 802.3af/at compliant PDs
- 802.1p/DSCP QoS enable smooth latency-sensitive traffic
- Supports PoE Power up to 30 W for each PoE port
- Supports PoE Power up to 40 W for all PoE ports
- Plug and play, no configuration and installation required
HARDWARE FEATURES
Interface:
– 5× 10/100/1000Mbps RJ45 Ports
– AUTO Negotiation
– AUTO MDI/MDIX
Network Media :
– 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
– 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
– 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity: Fanless
External Power Supply: External Power Adapter (Output: 53.5 VDC / 0.81 A)
Packet Forwarding Rate: 7.44 Mpps
PoE Ports (RJ45)
– Standard: 802.3 af/at compliant
– PoE Ports: Ports 1–4
– Power Supply: 40 W
Mac Address Table: 2K
Jumbo Frame: 16 KB
Switching Capacity: 10 Gbps
Dimensions ( W x D x H ): 3.9×3.9×1.0 in (99.8×98×25 mm)
Max Power Consumption:
– 4.12 W (220/50 Hz. no PD connected)
– 47.5 W (220/50 Hz. with 40 W PD connected)
Max Heat Dissipation:
– 14.05 BTU/h (no PD connected)
– 161.98 BTU/h (with 40 W PD connected)
