Network standards: IEEE 802.3/3u/3x, IEEE 802.3af/at
LED Indicator: 10* Link/Ack LED indicators
1 * Power LED indicator
Interfaces: 8 * 10/100 Base-TX Ethernet ports (Data/Power)
2 * 10/100 Base-TX Ethernet ports (Data)
Transmission media: Recommended: CAT5/5e UTP or better
Fan quantity: N/A
Dimension: 177.5mmx104.0mmx26.0mm
Level of protection:
Lightning protection for ports: 6KV
Lightning protection for power: 4KV
ESD:
Air discharge: ±10kV
Contact discharge: ±8kV
Forwarding mode: Store-and-forward
Switch capacity: 1.6 Gbps
Packet forwarding rate: 1.48Mpps
Buffer: 448K
MAC address table: 1K
Jombo frame: N/A
PoE budget: Single port: AF: 15.4W, AT: 30W
Whole device: 58W
Input voltage:
100－240V AC 50/60Hz
51V /1.25A DC（Power Adapter ）
Mounting:
Desktop mounting: support
Wall mounting: support
Rack mounting:non-support
Environment:
Operating Temperature: 0℃~45℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Certification: FCC、CE、RoHS
