Dimming without a neutral line. Shelly Dimmer 2 was developed to consider all possible electrical installations across the world. Shelly Dimmer 2 can be used in homes where the neutral line is missing and provide a full set of dimming functionalities. You can control a wide range of halogen lights, dimmable LED and ferromagnetic transformers.
Wireless
No hub required. Connect Shelly directly to your Wi-Fi network and control your home with your smartphone or tablet.
Control Remotely
Control a wide range of appliances directly from your smartphone or tablet from anywhere in the World as long as you have an Internet connection. All you need is a smartphone or tablet and the free Shelly Cloud mobile application.
Scheduling
Create a custom schedule to turn your devices on/off or dim to suit your lifestyle.
No Neutral Line Required
A Wi-Fi dimmer that can be used in homes where the neutral line is missing and provide a full set of dimming functionalities.
Temperature Sensor
Internal Temperature sensor for overheating protection.functionalities.
| POWER | |
| Power supply AC: | 110-230V ±10%, 50/60Hz |
| SPECIAL FUNCTIONS | |
| Device temperature protection: | Yes |
| Overload protection: | Yes |
| Power measurement: | Yes |
| Dimming: | Yes |
| Dimmable LED: | 50-200VA / 10W – 200W |
| Incandescent and halogen light sources: | 10-220W |
| Resistive-inductive loads ferromagnetic transformers: | 50-150VA |
| Working without a neutral line: | Yes |
| FEATURES | |
| Colour changing: | No |
| Predefined effects: | Yes |
| Channels: | 1 Channel |
| Operational temperature: | 0 to + 35 °C |
| Device power consumption: | < 1 W |
| Intelligent On/Off: | Yes |
| Local and remote control: | Yes |
| Sunrise/Sunset: | Yes |
| Weekly Schedule: | Yes |
| UL Listed option: | No |
| CONNECTIVITY | |
| Wireless/Wi-Fi protocol: | 802.11 b/g/n |
| Radiofrequency: | 2400 – 2500 MHz |
| Radio signal power: | 1mW |
| Range: | · Up to 50m outdoors · Up to 30m indoors (Depending on the building materials) |
| DIMENSIONS | |
| Size: | 42mm x 36mm x 14 mm |
