Storage
Supported storage drive interfaces: Serial ATA II, Serial ATA III
Storage drive sizes supported: 2.5, 3.5″
RAID support: Yes
RAID levels: 0, 1, 5, 6, 10, JBOD
Online RAID migration: Yes
Online RAID expansion: Yes
RAID rebuild: Yes
Hot-swap drive bays: Yes
Supported file systems: FAT32, HFS+, NTFS, ext3, ext4
Storage drives installed: No
Number of storage drives supported: 12
Installed storage drive type: No
Supported storage drive types: HDD & SSD
Bad block scan: Yes
Disk roaming: Yes
Processor
Processor manufacturer: Annapurna Labs
Processor type: Annapurna Labs
Processor: AL324
Processor frequency: 1,7 GHz
Processor number of cores: 4
Memory
Internal memory: 4 GB
Internal memory type: DDR4
Maximum RAM supported: 16 GB
Memory slots: 1
Memory form factor: UDIMM
Flash memory: 512 MB
Ports & interfaces
USB port: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Fiber ports quantity: 2
Fiber optic connector: SFP+
Ethernet LAN (RJ-45) ports: 2
Performance
Type: NAS
Device class: Small & Medium Business
Backup function: Yes
Backup features: Cloud, iSCSI LUN
Buzzer: Yes
Multilingual support: Yes
Noise level: 32,2 dB
Snapshot: Yes
Management protocols: SNMP
Web-based management: Yes
Encryption type: 256-bit AES, FIPS 140-2, HTTPS, SSH, SSL/TLS
Access Control List (ACL): Yes
Reset button: Yes
On/off switch: Yes
Built-in FTP server: Yes
Browser supported: Mozilla Firefox, Microsoft Internet Explorer 10+, Apple Safari 7+, Google Chrome
System log: Yes
Hot spare: Yes
Disk scan: Yes
S.M.A.R.T. support: Yes
Share folder: CIFS/SMB
Universal Plug and Play (UPnP): Yes
USB copy function: Yes
Power
Power supply location: Built-in
Power supply unit (PSU) capacity: 250 W
Number of power supply units: 2
Power consumption (typical): 83,57 W
AC input voltage; 100 – 240 V
AC input frequency: 50 – 60 Hz
Fan voltage: 12 V
Weight & dimensions
Width: 482 mm
Depth: 534 mm
Height: 89 mm
Weight: 11,3 kg
