Data Capture
Image Sensor: 640×480 CMOS
Aiming: Red LED
Illumination: White LED
Resolution: ≥3mil
Depth of Field EAN 13 (13mil): 50mm-280mm
Depth of Field Code 39 (5mil): 50mm-120mm
Depth of Field PDF417 (6.7mil): 40mm-120mm
Depth of Field DataMatrix (10mil): 30mm-125mm
Field of View Horizontal: 45°
Field of View Vertical: 34°
Scan Angle Roll: 360°
Scan Angle Pitch: ±60°
Scan Angle Skew: ±60°
Minimal Print Contrast: 20%
Performance
Memory Flash: ≥16,384 code entries (above 60 bytes)
Physical
Battery Type: 600mAh lithium-ion battery
Dimensions (mm): Cradle: 140x90x144,5mm
Dimensions (mm): Scanner: 117,5×67,5x144mm
Expected Battery Life: ≥16 hours of continuous operation (scan once per 6 seconds)
Expected Charge Time: ≤6 hours
Input Voltage: 5V DC±5%
Interfaces: USB (Type A), support USB-KBW, USB-CDC, HID-POS
Notifications: Beep, LED, Vibration
Weight Cradle: 340,5g
Weight Scanner: 209g
Wireless
Radio Technology: Bluetooth 5.0
Wireless Distance (max.): ≥100m (in open space)
Communication Modes: Synchronous, asynchronous and batch mode
Environmental
Operating Temperature: -10°C to 50°C (14°F to 122°F)
Storage Temperature: -40 to 70°C (-40°F to 158°F)
Charge Temperature: 0°C to 45°C (32°F to 113°F)
Humidity: 5%~95% (non-condensing)
Electro Static Discharge (ESD): ±8 KV (contact discharge); ±15 KV (air discharge)
Drop: Scanner: 1.5m drops to concrete (cradle: 1,2m)
IP Rating: IP52
