The point of sale (POS) system is the heart of any retailer. It’s the touch point with shoppers, who expect an increasingly fast and engaging experience. The FR80 Salmon drives transactions and loyalty by combining all the features you need for a plug-and-play manned or self-service counter.
| 1D | All major 1D symbologies, including EAN-13, EAN-8, UPC-A, UPC-E, Code 128, Code 39, Codabar, UCC/EAN 128, RSS, Interleaved 25, ITF 14, ITF 6, Standard 25, Matrix 25, COOP 25, Industrial 25, Plessey, MSI Plessey, Code 11, Code 93, Code 49, Code 16K. |
| 2D | All major 2D symbologies, including PDF417, QR Code, Data Matrix, Micro PDF417, Micro QR. |
| Image Sensor | 1280 * 1088 CMOS |
| Illumination | Red LED (614nm-624nm) |
| Scan Modes | Advanced sense mode |
| Depth of Field EAN 13 (13mil) | 0mm-140mm |
| Field of View Horizontal | 42.4° |
| Field of View Vertical | 36° |
| Scan Angle Roll | 360° |
| Scan Angle Pitch | ±55° |
| Scan Angle Skew | ±50° |
| Minimal Print Contrast | >15% |
| Motion Tolerance | 3.5m/s |
| Current @ 5VDC Operating | 400mA (typical) |
| Current @ 5VDC Standby | <100mA |
| Dimensions (mm) | Without base: 151 (W) x 141.5 (H) x 97.5 (D) mm; With base: 151 (W) x 156.5 (H) x 108.5 (D) mm |
| Input Voltage | 5 VDC±5% |
| Interfaces | RS-232, USB |
| Notifications | Beep, LED indicator |
| Power Consumption | 2W (typical), 2.5W (max.) |
| Weight | 542g (without base), 678g (with base) |
| More info: | https://www.newland-id.com/en/products/presentation-scanners/fr80-salmon |
