Image Display
Display System 0.64″ LCD
Native Chip Resolution 1920 x 1200 (WUXGA)
Supported Resolutions Maximum: UHD 4K – 3840 x 2160 @ 30 Hz
Max Brightness 3800 Lumens
Aspect Ratio Native: 16:10
Dynamic Contrast Ratio 16,000:1
Scan Horizontal: 15 to 100 kHz
Vertical: 50 to 120 Hz
Lens
Focus: Manual
Lens: f/1.5 – 2.08 (f = 17.2 – 27.7 mm)
Optical Zoom: 1.6x
Throw Distance: 2.6 – 42.3′ / 0.792 – 12.893 m
Throw Ratio: 1.2 to 2:1
Projection Size: 30 – 300″ / 76.20 – 762.00 cm
Inputs/Outputs:
2 x HDMI (HDMI Type-A) Audio, Video Input
1 x USB 2.0 (USB Type-A) Data Input
1 x VGA (DE-15/DB-15) Video Input
1 x VGA (DE-15/DB-15) Video Output
1 x Composite (RCA) Video Input
1 x 2RCA Audio Input
1 x 1/8″ / 3.5 mm Mini Audio Input
1 x 1/8″ / 3.5 mm Mini Audio Output
1 x Ethernet (RJ45) Control, LAN
1 x RS-232 (DE-9/DB-9) Control Input
1 x USB 2.0 (USB Type-B) Service
