System
- Operation system Linux
Display
- Size 7-inch
- Type Touch screen
Video
- FOVH FOV= 75.5°; VFOV= 41.5°; DFOV= 87°
- Pixel 2 MP
- Lens Dual-lens
- Video standard PAL (Default)/NTSC
Network
- Wi-Fi Support, 2.4 G, 802.11b/g/n
- Wired network Support 10/100/1000 Mbps self-adaptive
Interface
- Alarm input 2
- Alarm output 1
- USB 1 (For Module)
- Audio Output Interface 1 (3.5 mm)
- Network interface 1
- RS -485 1
- Wiegand 1
- Lock output 1
- Exit button 1
- Door contact input 1
- TAMPER 1
Capacity
- Card capacity 500,000
- Face capacity 100,000
- Event capacity 150,000
Authentication
- Face recognition accuracy rate ≥ 99%
- Card type M1 card; DES fire card; Felica card
- Card reading distance 0 to 3 cm
- Card reading duration ＜ 1 s
- Face recognition duration ＜ 0.2 s per person
- Face recognition distance 0.3 to 3 m
General
- Power supply 12 VDC to 24 VDC/2 A
- Working temperature -30 °C to 60 °C (-22 °F to 140 °F)
- Working humidity 0 to 90% (no condensing)
- Protective level IP65
- Dimensions 110.5 mm × 209.2 mm × 24 mm (4.35″ × 8.24″ × 0.94″)
- Language English, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil), Japanese, Korean
- Weight Gross Weight：1.06 kg (2.34 lb)Net Weight：0.57 kg (1.26 lb)
Function
- Two-way audio Support
- Time synchronization Support
- Face anti-spoofing Support
- Live view Support
- Audio prompt Support
