Thermal Module
- Image Sensor Vanadium Oxide Uncooled Focal Plane Arrays
- Resolution 160 × 120
- Pixel Pitch 17 μm
- Spectral Range 8 μm to 14 μm
- NETD < 50 mK (25°C, F1.2)
- Focal Length 1.31 mm
- IFOV 11.33 mrad
- Field of View 110° (H)x82° (V)
- Min. Focusing Distance 0.1 m
- Aperture F1.2
Smart Function
- Temperature Range -10°C to 200°C (14°F to 392°F)
- Temperature Accuracy ± 8°C (± 14.4°F)
Video and Audio
- Main Stream Thermal:25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240)
- Sub-stream Thermal:25 fps (704 × 576, 352 × 288, 320 × 240)
- Third Stream Thermal:25 fps (320 × 240, 352 × 288, 704 × 576, 1280 ×720)
- Video Compression H.265/H.264
Network
- Protocols IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP
- Network Storage MicroSD/SDHC/SDXC card (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
- API ISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface (Profile S, Profile G)
- Simultaneous Live View Up to 20 channels
- User/Host level Up to 32 users, 3 levels: Administrator, Operator, User
- Security User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
- Client iVMS-4200, Hik-Connect
- Web Browser Live view (plug-in allowed) : Internet Explorer 11Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 +Local service : Chrome 57.0 +, Firefox 52.0 +
Mobile Communication
- Wi-Fi Wi-Fi standard: IEEE802.11b, 802.11g, 802.11nFrequency range: 2.4GHz~2.4835GHzChannel band, with: Support 20MHz, Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Interface
- Alarm Output 1, alarm output (alarm response actions configurable)
- Alarm Action SD recording/Relay output/Smart capture/FTP upload
- Communication Interface 1, RS-485 interface (half duplex)
- Reset Key 1 reset button built in the motherboard
General
- Web Client Language 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
- Power Supply 5-16 VDC, type-C, PoE available (type-C to PoE convertor)
- Power Consumption 5-16 VDC: 0.22-0.7 A, Max. 3.5 W
- Working Temperature/Humidity Temperature: -10°C to 50°C (14°F to 122°F)Humidity: 95% or less
- Dimensions φ70mm × 25 mm (φ2.75″ × 0.98″)
- Weight 100 g (0.22 lb)
