Camera
- Image Sensor [Bullet channel]: 1/2.5″ Progressive Scan CMOS; [PTZ channel]: 1/2.8″ progressive scan CMOS
- Max. Resolution [Bullet channel] 3632 × 1632, [PTZ channel] 1920 × 1080
- Min. Illumination [Bullet channel]: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light;[PTZ channel]: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR
- Shutter Speed1 s to 1/30,000 s
- Day & Night ICR
- Zoom [PTZ channel] 25 × optical, 16 × digital
- Slow Shutter yes
Lens
- Focal Length [Bullet channel]: 2.8 mm; [PTZ channel]: 4.8 to 120 mm, 25 × optical
- FOV [Bullet channel]: Horizontal field of view: 180±10°, Vertical field of view: 80±5°;[PTZ channel]:Horizontal field of view: 54.8° to 2.8° (wide-tele),Vertical field of view: 31.4° to 1.5° (wide-tele),Diagonal field of view: 62.2° to 3.2° (wide-tele)
- Focus semi-auto||manual||auto
- Aperture [Bullet channel]: F1.0; [PTZ channel]: F1.6
- Zoom Speed [PTZ channel]: approx. 3.6 s
Illuminator
- Supplement Light Type [PTZ channel]: IR; [Bullet channel]: White Light
- Supplement Light Range [PTZ channel]: up to 100 m; [Bullet channel]: up to 30 m
- Smart Supplement Light Yes
PTZ
- Movement Range (Pan) 360°
- Movement Range (Tilt) -15° to 90° (auto flip)
- Pan Speed pan speed: configurable from 0.1° to 80°/s; preset speed: 80°/s
- Tilt Speed tilt speed: configurable from 0.1° to 80°/s, preset speed 80°/s
- Proportional Pan yes
- Presets 300
- Preset Freezing yes
- Patrol Scan 8 patrols, up to 32 presets for each patrol
- Pattern Scan 4 pattern scans
- Park Action preset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan
- 3D Positioning yes
- PTZ Status Display yes
- Scheduled Task preset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan||dome reboot||dome adjust||aux output
- Power-off Memory yes
Video
- Main Stream [Bullet channel]50 Hz：25 fps（3632 × 1632，3680 × 1656）60 Hz：30 fps（3632 × 1632，3680 × 1656）[PTZ channel]50 Hz：25 fps（1920 × 1080，1280 × 960，1280 × 720）60 Hz：30 fps（1920 × 1080，1280 × 960，1280 × 720）
- Sub-Stream [Bullet channel]50 Hz：25 fps（1200 × 536，960 × 432）60 Hz：30 fps（1200 × 536，960 × 432）[PTZ channel]50 Hz：25 fps（704 × 576，640 × 480，352 × 288）60 Hz：30 fps（704 × 480，640 × 480，352 × 240）
- Third Stream [Bullet channel]No[PTZ channel]50 Hz：25 fps（1920 × 1080，1280 × 960，1280 × 720，704 × 576，640 × 480，352 × 288）60 Hz：30 fps（1920 × 1080，1280 × 960，1280 × 720，704 × 480，640 × 480，352 × 240）
- Video Compression H.265||H.264||MJPEG
- Video Bit Rate 32 kbps to 16384 kbps
- H.264 Type baseline profile||main profile||high profile
- H.265 Type main profile
- Scalable Video Coding (SVC) H.264 and H.265 encoding
- Region of Interest (ROI) 8 fixed regions for each stream
Audio
- Audio Compression G.711,G.722.1,G.726,MP2L2,PCM,AAC-LC,MP3
- Audio Bit Rate MP2L2: 32 Kbps, 40 Kbps, 48 Kbps, 56 Kbps, 64 Kbps, 80 Kbps, 96 Kbps, 112 Kbps, 128 Kbps, 144 Kbps, 160 Kbps, 192 Kbps, AAC-LC: 16 Kbps, 32 Kbps, 64 Kbps , MP3: 8Kbps, 16Kbps, 24Kbps, 32Kbps, 40Kbps, 48Kbps, 56Kbps, 64Kbps, 80Kbps, 96Kbps, 112Kbps, 128Kbps, 160Kbps, 192Kbps, 224Kbps, 256Kbps, 320Kbps
- Audio Sampling Rate MP2L2: 16 kHz, 32 kHz, 48 kHz; AAC-LC: 16 kHz, 32 kHz, 48 kHz; PCM: 8 kHz, 16 kHz, 32 kHz, 48 kHz; MP3: 8 kHz, 16 kHz, 32 kHz, 48 kHz
- Environment Noise Filtering yes
Network
- Protocols IPv4/IPv6||HTTP||HTTPS||802.1x||Qos||FTP||SMTP||UPnP||SNMP||DNS||DDNS||NTP||RTSP||RTCP||RTP||TCP/IP||UDP||IGMP||ICMP||DHCP||PPPoE||Bonjour||WebSocket||Web Sockets
- Simultaneous Live View 20
- API ISAPI,SDK,ISUP,ONVIF
- User/Host 32
- Security Authenticated username and password||MAC address binding||HTTPS encryption||802.1X authenticated access||IP address filter
- Network Storage NAS (NFS, SMB/ CIFS)|| ANR
- Client iVMS-4200||Hik-Connect
- Web Browser IE11+, Chrome57+, Firefox52+, Safari12+, Edge79.0.309.65+
- Image Parameters Switch Yes
- Image Settings sharpness, saturation, brightness, contrast
- Day/Night Switch day, night, auto, scheduled-switch
- Wide Dynamic Range (WDR) 120 dB
- SNR ≥ 52 dB
- Defog Digital defog
- Image Stabilization EIS
- Image Enhancement BLC,HLC,3D DNR
- Privacy Mask [Bullet channel] 8 programmable polygon privacy masks, [PTZ channel] 24 programmable polygon privacy masks; mask color or mosaic configurable
- Regional Focus Yes
- Regional Exposure Yes
Interface
- Ethernet Interface RJ45, self-adaptive 10M/100M Ethernet port
- On-board Storage Built-in memory card slot, support Micro SD/Micro SDHC/Micro SDXC, up to 256 GB
- Audio 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω
- Alarm 1 alarm input, 1 alarm output
- Reset yes
Event
- Basic Event Motion detection, video tampering alarm, exception (IP address conflict, HDD full, illegal login, HDD error, network disconnected, Abnormal Reboot),alarm input and output
- Smart Event audio exception detection, region entrance detection, region exiting detection, intrusion detection, Line crossing detection
- Linkage Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, and PTZ actions (such as preset, patrol scan, pattern scan)
- Smart Linkage Panorama Linkage
Deep Learning Function
- Face Capture Detects up to 30 faces simultaneously, Supports detecting, tracking, capturing, grading, selecting of face in motion, and outputs the best face picture
General
- Power 12VDC, PoE+
- Dimension Ø 166 mm × 375 mm (Ø 6.5″ × 14.7″)
- Weight Approx. 2.4 kg (13.2 lb.)
- Material ADC12
- Operating Condition -30℃ to 65℃ (-22°F to 149°F) ||humidity lower than 90%RH
- General Function mirror, password protection, watermark
- Demist Demist by heating the glass
- Power Consumption and Current Max. 24 W, including max. 2.6 W for heater and max. 11 W for supplement light
Approval
- Protection IP66 Standard, 6000 V Lightning Protection, Surge Protection and Voltage Transient Protection
