Temperature measurement
- Temperature range 30 °C to 45 °C (86 °F to 113 °F)
- Sensor Vanadium Oxide uncooled sensor
- Resolution 120 × 160
- Frame rate 25 fps
- Measurement accuracy 0.1 °C
- Measurement deviation ± 0.5 °C
- Measuring distance 0.3 to 1.8 m
Display
- Size 7-inch
- Type Touch screen
Video
- FOVH FOV= 46°; VFOV= 87°
- Pixel 2 MP
- Lens Dual-lens
Network
- Wired network Support, 10/100/1000 Mbps self-adaptive
Interface
- Network interface 1
- RS -4851
- Wiegand 1
- Lock output 1
- Exit button 1
- Door contact input 1
- IO input 2
- IO output 1
- TAMPER 1
Capacity
- Card capacity 6000
- Face capacity 6000
- Event capacity 100,000
Authentication
- Card type M1 card
- Card reading distance 0 to 5 cm
- Card reading duration＜ 1 s
- Face recognition duration＜ 0.2 s per person
- Face recognition distance 0.3 to 1.8 m
General
- Power supply 12 VDC/2 A
- Working temperature 0 °C to 50 °C (32 °F to 122 °F)For temperature measurement: 10 °C to 35 °C (50 °F to 95 °F)
- Working humidity 10 to 90% (No condensing)
- Application environment Indoor and windless environment use only
- Weight Gross Weight: 1.89 kg (4.17 lb)Net Weight: 1.04 kg (2.29 lb)
Function
- Face anti-spoofing Support
- Live view Support
- Audio prompt Support
