System parameters
- Operation system Linux
- ROM 32 MB
- RAM 256 MB
- Processor Embeded high performance processor
Display parameters
- Screen size /
- Operation method /
- Type /
- Resolution /
Video parameters
- Lens 1
- Resolution Main stream: 1920 × 1080p, 720pSub stream: 640 × 480p
- FOV Horizontal: 131° Vertical: 78°
- Wide dynamic range (WDR) Support 120 dB
- Supplement light IR light, up to 3 m
- Video compression standard H.264
Audio parameters
- Audio input 1 built-in omnidirectional microphone
- Audio compression standard G.711 U
- Audio output 1 built-in loudspeaker
- Audio compression bitrate 64 Kbps
- Audio quality Noise suppression and echo cancellation
- Volume adjustment Adjustable
Capacity
- User capacity 2000
- Face capacity /
- Card capacity 10000
Network parameters
- Network protocol TCP/IP, RTSP
- Wi-Fi IEEE 802.11b, IEEE802.11g, IEEE802.11n
- Bluetooth Not supported.
- 3G/4G /
Device interfaces
- Alarm input 4
- Network interface 1 RJ-45, 10/100 Mbps self-adaptive
- TAMPER 1
- Exit button 1
- RS-485 1
- USB /
- Wiegand /
- TF card Reserved
- Alarm output /
- Lock control 1 relay, Max. 30 VDC 2 A
- Door contact input 1
General
- Button 1 physical button
- Installation Surface mounting
- Indicator 2
- Weight Net weight: 0.190 kg Gross weight: 0.414 kg
- Protective level IP65
- Working temperature -40 °C to 55 °C(-40 °F to 131 °F)
- Working humidity 10% to 95% (no-condensing)
- Dimension (W × H × D) 138 mm × 65 mm × 27 mm (5.4″ × 2.6″ × 1.1″)
- Battery /
- Application environment Outdoor
- Power consumption ＜ 10 W
- Language English, French, Portuguese (Brazil), Spanish, Russian, German, Italian, Polish, Arabic, Turkish, Vietnamese, Hungarian, Dutch, Romanian, Czech, Bulgarian, Ukrainian, Croatian, Serbian, Portuguese, Slovak
- Power supply 12 VDC, Standard PoE, af
