Hikvision POE

• Input Current : 2A
• Output Voltage Range : 54V~57V
• Output Power : 60W
• Pass Through Data Rates : 10/100/1000 Mbps
• Ports : Two 10/100/1000M adaptive RJ45 ports, one is DATA/IN, another is PoE/DATA
• LED Indicator : Power & PoE Status(The module operates normally when MID and END are on)
• Base Function : Compliance to IEEE 802.3 at/af Standard for PD

Network Medium

• 10BASE-T: unshielded twisted pair category 3, 4 or 5
• 100BASE-TX: unshielded twisted pair category 5 and above
• 1000BAST-TX: unshielded twisted pair category 5 and above
• Protection Methods : Output Over Current Protection, Short Circuit Protection
• Operating Humidity : 5% ~ 90%
• Weight : 473g
• Dimension : 185mm*70.8mm*37mm (L*W*H)
• Operating Temperature : -20 ~ 60 °C
