Camera | |
Image Sensor | 1/1.8″ Progressive Scan CMOS |
Max. Resolution | 2.8 mm |
Panorama+ePTZ mode: panorama channel: 1920 × 1080; ePTZ channel: 1920 × 1080 | |
Panorama mode: 3840 × 2160 | |
Original mode: 1920 × 1080 | |
6 mm | |
Panorama+ePTZ mode: panorama channel: 2400 × 400; ePTZ channel: 1920 × 1080 | |
Panorama mode: 6480 × 1080 | |
Original mode: 1920 × 1080 | |
Min. Illumination | Color: 0.003 Lux @ (F1.2, AGC ON); B/W: 0.0018 Lux @ (F1.6, AGC ON),0 Lux with IR |
Shutter Time | 1/25 s to 1/100,000 s |
Day & Night | IR cut filter. Blue glass module to reduce ghost phenomenon. |
Angle Adjustment | Pan: 0° to 355°, tilt: 0° to 90° |
Lens | |
Lens Type | Fixed focal lens, 2.8 mm and 6 mm optional, four lenses |
Focal Length | 2.8 mm: horizontal FOV 180°, vertical FOV 90° |
Lens Mount | M16 |
Focus | Manual, semi-auto |
Aperture | F1.4 |
Video | 2.8 mm |
Panorama+ePTZ mode: panorama channel: 50Hz: 25fps (1920 × 1080, 1280 × 720), 60Hz: 30fps (1920 × 1080, 1280 × 720); ePTZ channel: 50Hz: 25fps (1920 × 1080, 1280 × 720), 60Hz: 30fps (1920 × 1080, 1280 × 720) | |
Panorama mode: 50Hz: 25fps (3840 × 2160 , 2560 × 1440 , 1920× 1080), 60Hz: 30fps (3840 × 2160 , 2560 × 1440 , 1920× 1080) | |
Original mode: 50Hz: 25fps (1920× 1080), 60Hz: 30fps (1920× 1080) | |
Sub-Stream | 2.8 mm |
Panorama mode: 50Hz: 25fps (1280 × 720, 640 × 360), 60Hz: 30fps (1280 × 720, 640 × 360) | |
Video Compression | Main stream: H.265+/H.265/H.264+/H.264 |
Sub-stream: H.265/H.264/MJPEG | |
Video Bit Rate | 32 Kbps to 65 Mbps |
H.264 Type | Baseline Profile,Main Profile,High Profile |
H.265 Type | Main Profile |
Scalable Video Coding (SVC) | H.264 and H.265 encoding |
Target Cropping | Yes (only panorama mode supports) |
Image | |
Image Settings | Rotate mode (only the original mode supports), saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser |
Day/Night Switch | Day,Night,Auto,Schedule,Alarm Trigger |
Wide Dynamic Range (WDR) | Digital WDR |
Image Enhancement | BLC, HLC, 3D DNR, Defog, EIS (only the original mode supports) |
Picture Overlay | LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format |
Interface | |
Ethernet Interface | 1 RJ45 10 M/100 M/1000 M Ethernet port |
On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB |
Audio | 1 input (line in), 3.5 mm 3-section connector, max. input amplitude: 1 vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; |
1 output (line out), 3.5 mm 3-section connector, max. output amplitude: 1 vpp, output impedance: 100 Ω, interface type: non-equilibrium | |
Alarm | 2 inputs, 2 outputs (max. 24 VDC, 1A) |
RS-485 | 1 RS-485 interface (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
Reset Key | Yes |
