System parameters
- Operation system Linux
- ROM 4 GB
- RAM 1 GB
- Processor Embeded high performance processor
Display parameters
- Screen size 4.3-inch
- Operation method Capacitive touch screen
- Type IPS
- Resolution 800 × 480
- Luminance 425 cd/m²
Video parameters
- Lens 2
- Resolution 2 × 2 MP
- FOV Horizontal: 88°, Vertical: 44°
- Wide dynamic range (WDR) Support 120 dB
- Supplement light IR light, up to 3 m
- Video compression standard Main stream and sub stream: H.264Third stream: H.265
Audio parameters
- Audio input 1 built-in omnidirectional microphone
- Audio compression standard G.711u、G.711a、Opus、AAC-LD、AAC-LC、G.726、G.722.1
- Audio output 1 built-in loudspeaker
- Audio compression bitrate G.711u、G.711a、Opus：64kbps；G.722.1、G.726：32kbps；AAC-LD、AAC-LC：16kbps
- Audio quality Noise suppression and echo cancellation
- Volume adjustment Adjustable
Capacity
- User capacity 20000
- Face capacity 10000
- Fingerprint capacity /
- Card capacity 100000
- Message capacity /
- Linked indoor station capacity 500
- Sub door station capacity 16
Network parameters
- Network protocol TCP/IP, RTSP
- Wi-Fi IEEE802.11b, IEEE802.11g, IEEE802.11n
- Bluetooth Support：2.0
- 3G/4G /
Authentication
- Card reading frequency 13.56 MHz
- Face recognition distance 0.3 to 2 m
- Face recognition accuracy rate ≥ 99%
- Face recognition duration ＜ 0.2 s per person
Device interfaces
- Alarm input 4 (2 exit butttons and 2 door contacts by default)
- Network interface 1 RJ-45, 10/100 Mbps self-adaptive
- TAMPER 1
- Exit button 2
- RS-485 1
- USB /
- Wiegand /
- TF card Reserved
- Lock control 2 relays, Max. 30 VDC 2 A,lock 2 needs secure module
- Door contact input 2
General
- Button 1 physical button
- Installation Surface mounting
- Indicator /
- Weight Net weight: 0.405 kg Gross weight: 0.752 kg
- Protective level IP65, IK08
- Working temperature -40 °C to 60 °C (-40 °F to 140 °F)
- Working humidity 10% to 90% (no-condensing)
- Dimension (W × H × D) 182 mm × 85 mm × 26 mm (7.16″ × 3.34″ × 1.01″)
- Battery /
- Power supply 12 VDC, 1.5 A,IEEE802.3af, Standard PoE
- Application environment Outdoor
- Power consumption ≤ 6 W
- Language English,French,BrazilianPortuguese,Spanish,Russian,German,Italian,Polish,Turkish,Vietnamese,Arabic,Czech,Hungarian,Dutch,Romanian,Bulgarian,Ukrainian,Croatian,Serbian,Greek
