Display
Screen Size: 65″
Backlight: DLED
Pixel Pitch: 0.124 (H) × 0.372 (V) mm
Resolution: 3840 × 2160, 60 Hz
Brightness: 350 cd/m²(Typ.)
Colour Depth: 10 bit
Contrast Ratio: 5000 : 1 (Typ.)
Response Time: 6ms
Colour Gamut: 90% NTSC (CIE1931) (Typ.)
Refresh Rate: 60 Hz
Viewing Angle: 178° (H) / 178° (V)
Surface Haze: 25%Haze
Display Area: 1428.48mmx803.52mm
Working Duration: 7 * 16 H
Touch
Type: Infrared touch screen
Glass: AG smooth glass
Touch Point: Max 45 point multi-touch
Touch Response Time: < 10ms
Touch Precision: ± 1 mm (≥ 90% touching area)
Built-in System
Operation System: Android 11
Processor: A722 + A534, 1.8 GHz
Memory: 4 GB
Built-in Storage: 64 GB
NIC: Built-in 1000 Mbps NIC, supporting routing; IEEE 802.11 a/b/g/n/ac with 2 × 2 MIMO, supporting both 2.4 GHz and 5GHz bands
Camera
Pixel: 8 MP
Camera Function: Smart switch between Android system and OPS
Field Angle: 120°(diagonal), 110°(horizontal), 66°(vertical)
Distortion: ≤6%
Camera Resolution Ratio: Up to 4K
Microphone
Specification: Omni-directional 6-array layout
Mic Function: Echo reduction and smart noise-cancellation
Voice Distance: 8 m
Sampling Rate: 32 K
Mic Sampling Rate: 16 bit
Internal Function
Loudspeaker: Built-in 2 × 16 W loudspeaker
Bluetooth: Built-in BLE (Bluetooth Low Energy) module supports Bluetooth 5.0 and previous version
Interface
Video & Audio Input: HDMI IN × 2, MAX 4K @30 Hz, LINE IN × 1
Video & audio output: HDMI OUT(HDMI 2.0) × 1, MAX 4K @60 Hz, LINE OUT × 1
Control interface: RS-232 × 1, Touch-USB × 1
Network Interface: RJ45 (1000 Mbps port) × 2
Data Transmission Interface: USB-C × 1, USB-A × 2 on front panel, USB-A × 2 on rear panel
Power
Power Consumption: ≤ 320 W (full load)
Standby Consumption: 0.5 W
General
Power: 100 to 240 V, AC, 50/60 Hz
Product dimensions: 1507 × 930 × 86 mm
Package Dimensions (W × H × D): 1687 × 1061 × 234 mm
Net Weight: 40.36 kg
Gross Weight: 50.69 kg
Lifespan: 50000 hours
