System parameters
- Operation system Android 10.1
- ROM 8 GB
- RAM 2 GB
- Processor Embeded high performance processor
Display parameters
- Screen size 7-inch
- Operation method Capacitive touch screen
- Type Colorful TFT
- Resolution 1024 × 600
Video parameters
- Lens /
- Resolution /
- FOV /
- Wide dynamic range (WDR) /
- Video compression standard /
- Focal length /
Audio parameters
- Audio input 1 built-in omnidirectional microphone
- Audio compression standard G.711U, G.711A
- Audio output 1 built-in loudspeaker
- Audio compression bitrate 64 Kbps
- Audio quality Noise suppression and echo cancellation
- Volume adjustment Adjustable
Capacity
- Message capacity 200 captured pictures, 200 alarm records
- Notice capacity 200
- Linked indoor extensions capacity 16
- Linked network camera capacity 16
- Linked door phone capacity 17
Network parameters
- Network protocol TCP/IP, SIP, RTSP
- Wi-Fi 2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n
- Bluetooth /
- 3G/4G /
- Zigbee /
Device interfaces
- Alarm input 8
- Network interface 1 RJ-45 10/100 Mbps self-adaptive
- TAMPER /
- RS-485 1 RS-485 (Half duplex)
- TF card Support TF card, up to 128 G
- Alarm output 1
- Lock control 1 relay, Max. 30 VDC 0.3 A, and 1 high/low level relay (3.3 V/0V)
General
- Button /
- Installation Surface mounting
- Indicator /
- Weight Net weight: 419.3 g Gross weight: 694 g
- Protective level /
- Working temperature -10 °C to 50 °C (14 °F to 122 °F)
- Working humidity 10% to 90% (no-condensing)
- Dimension (W × H × D) 187 mm × 137 mm × 25.7 mm (7.36″ × 5.39″ × 1.01″)
- Battery /
- Power supply 12 VDC, 1 A, IEEE802.3af, standard PoE
- Application environment Indoor
- Power consumption ≤ 12 W
- Language English, Russian, Estonian, Bulgaria, Hungarian, Greek, German, Italian, Czech, Slovak, France, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Traditional Chinese, Vietnamese, Hebrew, Latvian, Lithuanian, Brazilian Portuguese, Arabic, Ukrainian, Mongolian
