Camera
- Image Sensor : 1/1.8″ Progressive Scan CMOS
- Max. Resolution : 2688 × 1520
- Min. Illumination : Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light
- Shutter Time : 1/3 s to 1/100,000 s
- Day & Night : IR cut filter
- Angle Adjustment : Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Lens
- Lens Type : Fixed focal lens, 4mm
- Focal Length & FOV : 4 mm, horizontal FOV 89.2°, vertical FOV 45.5°, diagonal FOV 108.2°
- Lens Mount : M16
- Iris Type : Fixed
- Aperture : F1.0
- Depth of Field : 4 mm: 3.1 m to ∞
DORI
- DORI : 4 mm: D: 75 m, O: 30 m, R: 15 m, I: 7 m
Illuminator
- Supplement Light Type : IR, White Light
- Supplement Light Range : Up to 60 m
- Smart Supplement Light : Yes
- IR Wavelength : 850 nm
Video
- Main Stream
- 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream
- 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
- Third Stream
- 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- *The third stream is supported under certain settings.
- Video Compression
- Main stream: H.265/H.264/H.264+/H.265+,
- Sub-stream: H.265/H.264/MJPEG,
- Third stream: H.265/H.264,
- *Third stream is supported under certain settings.
- Video Bit Rate : 32 Kbps to 8 Mbps
- H.264 Type : Baseline Profile, Main Profile, High Profile
- H.265 Type : Main Profile
- Bit Rate Control : CBR, VBR
- Scalable Video Coding (SVC) : H.264 and H.265 encoding
- Region of Interest (ROI) : 1 fixed region for main stream and sub-stream
Network
- Protocols : TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
- Simultaneous Live View : Up to 6 channels
- API : Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
- User/Host
- Up to 32 users
- 3 user levels: administrator, operator, and user
- Security : Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest
authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address) - Network Storage : NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
- Client : iVMS-4200, Hik-Connect, Hik-Central
- Web Browser
- Plug-in required live view: IE 10, IE 11,
- Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+,
- Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
- Image Parameters Switch : Yes
- Image Settings : Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
- Day/Night Switch : Day, Night, Auto, Schedule
- Image Enhancement : BLC, HLC, 3D DNR
- SNR : ≥ 52 dB
- Wide Dynamic Range (WDR) : 130 dB
- Privacy Mask : 4 programmable polygon privacy masks
Interface
- Ethernet Interface : 1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage : Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
- Reset Key : Yes
