Camera
Image Sensor: 1/2.8″ Progressive Scan CMOS
Max. Resolution: 1920 × 1080
Min. Illumination: Colour: 0.005 Lux @ (F1.6, AGC ON); B/W: 0.001 Lux @ (F1.6, AGC ON)
Shutter Speed: 1 s to 1/30,000 s
Day & Night: IR cut filter
Zoom: 25x optional, 16x digital
Slow Shutter: Yes
Lens
Focal Length: 4.8 mm to 120 mm
FOV
Horizontal field of view: 57.6° to 2.5° (wide-tele),
Vertical field of view: 34.4° to 1.4° (wide-tele),
Diagonal field of view: 64.5° to 2.9° (wide-tele)
Focus: Auto, semi-auto, manual
Aperture: Max. F1.6
Zoom Speed: Approx. 3.6 s
PTZ
Movement Range (Pan): 360°
Movement Range (Tilt): -5° to 90° (auto flip)
Pan Speed: Pan speed: configurable from 0.1° to 250°/s; preset speed: 300°/s
Tilt Speed: Tilt speed: configurable from 0.1° to 150°/s, preset speed 200°/s
Proportional Pan: Yes
Presets: 300
Preset Freezing: Yes
Patrol Scan: 8 patrols, up to 32 presets for each patrol
Pattern Scan: 4 pattern scans
Park Action: Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan
3D Positioning: Yes
PTZ Status Display: Yes
Scheduled Task: Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output
Power-off Memory: Yes
Video
Main Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Third Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Video Compression
Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264/MJPEG
Video Bit Rate: 32 Kbps to 16 Mbps
H.264 Type: Baseline profile/Main profile/High profile
H.265 Type: Main profile
Scalable Video Coding (SVC): H.264 and H.265 encoding
Region of Interest (ROI): 8 fixed regions for each stream
Audio
Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32-192 Kbps (MP2L2)
Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/48 kHz
Environment Noise Filtering: Yes
Image Parameters Switch: Yes
Image Settings: Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
Day/Night Switch: Day, Night, Auto, Schedule
Wide Dynamic Range (WDR): 120 dB
SNR: ＞52 dB
Defog: Digital Defog
Image Enhancement: BLC, HLC, 3D DNR
Privacy Mask; 24 programmable polygon privacy masks, mask color or mosaic configurable
Regional Focus: Yes
Regional Exposure: Yes
Ethernet Interface: 1 RJ45 10M/100M self-adaptive Ethernet port
On-board Storage: Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
Audio: 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%;
1 output (line out), line level, output impedance: 600 Ω
Alarm: 2 inputs, 1 output
Reset: Yes
