Camera
Image Sensor: 2 MP CMOS
Max. Resolution: 1920 (H) × 1080 (V)
Min. Illumination: 0.01 Lux @ (F2.0, AGC ON), 0 Lux with white light
Shutter Time: PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
Day & Night: ICR
Angle Adjustment: Pan: 0 to 360°, Tilt: 0 to 180°, Rotation: 0 to 360°
Signal System: PAL/NTSC
Lens
Lens Type: Fixed focal lens, 2.8 mm, 3.6 mm and 6 mm optional
Focal Length & FOV: 2.8 mm, horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118°
Lens Mount: M12
Illuminator
Supplement Light Type: White Light; IR
Supplement Light Range: IR : Up to 60 m, White Light : Up to 60 m
Image Settings: Anti-Banding, Brightness, Sharpness, Smart IR
Frame Rate
TVI: 1080P @ 30 fps, 1080P @ 25 fps
AHD: 1080P @ 30 fps, 1080P @ 25 fps
CVI: 1080P @ 30 fps, 1080P @ 25 fps
CVBS: PAL/NTSC
Day/Night Mode: Auto/Color/BW (Black and White)
Wide Dynamic Range (WDR): Digital WDR
Image Enhancement: DWDR/BLC/HLC/Global
White Balance: Auto/Manual
AGC: Yes
