Camera
Image Sensor: 2 MP CMOS
Max. Resolution: 1920 (H) × 1080 (V)
Min. Illumination: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Time: PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
Day & Night: ICR
Angle Adjustment: Pan: 0° to 360°,Tilt: 0° to 75°,Rotate: 0° to 360°
Signal System: PAL/NTSC
Lens
Lens Type: 2.8 mm fixed focal lens
Focal Length & FOV: 2.8 mm, horizontal FOV: 105°, vertical FOV: 56°, diagonal FOV: 126°
Lens Mount: M12
Illuminator
Supplement Light Type: IR, White Light
Supplement Light Range: IR: Up to 20 m, White Light: Up to 20 m
Smart Supplement Light: Yes
Image Parameters Switch: STD/HIGH-SAT/HIGHLIGHT
Image Settings; Brightness, Sharpness, Anti-banding, AGC
Frame Rate
TVI: 1080p @25 fps/30 fps
CVI: 1080p @25 fps/30 fps
AHD: 1080p @25 fps/30 fps
CVBS: PAL/NTSC
Day/Night Mode: Auto/Colour/BW (Black and White)
Wide Dynamic Range (WDR): Digital WDR
Noise Reduction: 3D DNR/2D DNR
Image Enhancement: DWDR, BLC, HLC, Global
White Balance: Auto, Manual
