Camera
- Image Sensor 2 MP CMOS
- Signal System PAL/NTSC
- Max. Resolution 1920 (H) × 1080 (V)
- Min. Illumination 0.02 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter Time PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
- Day & Night IR Cut Filter
- Angle Adjustment Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
Lens
- Lens Type 2.8 mm Fixed Lens
- Focal Length & FOV 2.8 mm, horizontal FOV: 96.5°, vertical FOV: 48.9°, diagonal FOV: 120.5°
- Lens Mount M12
Illuminator
- Supplement Light Range Up to 20 m
- Frame Rate TVI: 1080p@25fps/30fpsAHD: 1080p@25fps/30fpsCVI: 1080p@25fps/30fpsCVBS: PAL/NTSC
- Wide Dynamic Range (WDR) Digital WDR
- Image Parameters Switch STD/HIGH-SAT
- Day/Night Mode Auto/Color/BW (Black and White)
- White Balance Auto
- Image Enhancement DWDR, BLC, Global
- Noise Reduction 2D DNR
- Image Settings Brightness, Mirror, Smart IR, Sharpness, AGC
Interface
- Video Output Switchable TVI/AHD/CVI/CVBS
General
- Language English
- Operating Condition -40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
- Material Plastic
- Communication HIKVISION-C
- Dimension 138.8 mm × 60.9 mm × 57.9 mm (5.465″ × 2.389″ 2.278″)
- Weight Approx. 145 g (0.32 lb.)
- Power 12 VDC ± 25%, Max. 3.3 W
Approval
- Protection IP67
