Video And Audio
- IP Video Input 2-ch (up to 18-ch)Up to 5 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras
- Analog Video Input 16-chBNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- HDTVI Input 1080p25, 1080p30, 720p25, 720p30
- AHD Input 1080p25, 1080p30, 720p25, 720p30
- HDCVI Input 1080p25, 1080p30, 720p25, 720p30
- CVBS Input PAL/NTSC
- HDMI Output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- VGA Output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- Audio Input 1-ch, RCA (2.0 Vp-p, 1 KΩ)
- Audio Output 1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
- Synchronous Playback 16-ch
Recording
- Video Compression H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Encoding Resolution 1080p lite/720p/VGA/WD1/4CIF/CIF
- Frame Rate Main stream: For 1080p stream access: 1080p lite/720p lite/WD1/4CIF/VGA@15fps; CIF@25fps (P)/30fps (N)For 720p stream access: 720p/WD1/4CIF/VGA@15fps; CIF@25fps (P)/30fps (N)For standard definition stream access: WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)Sub-stream: For 1080p and 720p stream access: CIF/QVGA@15fpsFor standard definition stream access: CIF/QVGA@25fps (P)/30fps (N)
- Video Bitrate 32 Kbps to 4 Mbps
- Dual-Stream Support
- Stream Type Video, Video & Audio
- Audio Compression G.711u
- Audio Bitrate 64 Kbps
Network
- Remote Connection 128
- Network Protocol TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, UPnP™, HTTPS, ONVIF
- Network Interface 1, RJ45 10M/100M/1000M self-adaptive Ethernet interface
Auxiliary Interface
- SATA 1, SATA interface
- Capacity Up to 10 TB capacity for each disk
- USB Interface Rear panel: 2 × USB 2.0
General
- Power Supply 12 VDC, 1.5 A
- Consumption ≤ 18 W
- Working Temperature -10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity 10% to 90%
- Dimension (W × D × H) 260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
- Weight ≤ 2.2 kg (4.9 lb)
