Printing
Resolution (maximum): 360 x 180 DPI
Maximum printing width (columns): 136
Colour: No
Maximum print speed: 576 cps
Maximum print speed (draft): 432 cps
Maximum print speed (LQ): 144 cps
Character pitch: 10, 12 cpi
Maximum copies: 6 copies
Built-in barcodes: Code 39, EAN13, EAN8, Interleaved 2/5, POSTNET, UPC-A, UPC-E
Bitmap fonts: Courier, Draft, OCR-B, Orator, Orator-S, Prestige, Roman, Script, Script C
Scalable fonts: Roman, Roman T, Sans Serif, Sans Serif H
Paper handling
Maximum print area: A3 (297 x 420 mm)
Paper tray media types: Envelopes, Labels, Roll
Features
Product colour: Grey
Buffer size: 128 KB
Sound pressure level (printing): 54 dB
Page description languages: Epson ESC/P2, PPDS
Ports & interfaces
Standard interfaces: Parallel, USB 2.0
Endurance
Print heads: 24-pin
Print direction: Bi-directional
Print head life: 400 million characters
Ribbon life (black, draft): 15 million characters
Mean time between failures (MTBF): 20000 h
Power
Power consumption (typical): 46 W
Power consumption (standby): 3 W
AC input voltage: 220 – 240 V
AC input frequency: 50 – 60 Hz
Operational conditions
Operating temperature (T-T): 5 – 35 °C
Operating relative humidity (H-H): 10 – 80%
System requirements
Windows operating systems supported: Windows 2000, Windows 7, Windows 8, Windows 98, Windows Vista, Windows XP, Windows XP Home x64
Bundled software: Epson Status Monitor
Weight & dimensions
Width: 693 mm
Depth: 405 mm
Height: 268 mm
Weight: 13 kg
