General specifications
Product Length/Depth: 412 mm
Product Height: 346 mm
Product Width: 214 mm
Product Weight: 33.4 kg
Battery
Battery type: Sealed, lead-acid
Battery replacement: Hot-swappable internal batteries and extended battery modules (EBMs)
Battery quantity: 8
Battery management: ABM & Temperature compensated charging method (user selectable)
Automatic battery test
Deep discharge protection
Automatic recognition of external battery units
Battery rating: 12 V / 9 Ah
Extended battery capability: Yes
Electrical output
Receptacle: (8) C13, (1) C19
Voltage: 230V
Wattage: 2700 W
Output power factor: 0.9
Output voltage range: 200/208/220/230/240 V +/- 2%
Output waveform: Sine wave
Output nominal voltage: 230V default (200/208/220/230/240V)
Voltage distortion output (linear load) – max: 3
Feed type: 1
Topology: Online/Double-conversion
VA rating: 3000 VA
Electrical input
Input connection: C20
Input nominal voltage: 230V default (200/208/220/230/240/250V)
Nominal frequency: 50/60 Hz
Input power factor: >.99
Input cord length: 1.8m
Input voltage range: 200-276 Vac without derating (up to 140-276 Vac with derating)
Input frequency range: 40-70 Hz
Warning:
Charging and discharging a battery multiple times a day will significantly deteriorate its performance. Please note the limitations of each battery technology:
- Lead-acid batteries can only be discharged up to 50% before irreversible damage occurs.
- Gel lead-batteries can often be discharged up to 70% before irreversible damage occurs.
- Lithium batteries can be fully discharged if they are protected by a Battery Management System.
Due to the above limitations, loss of battery capacity is not covered under warranty.
