Performance
Maximum video resolution: 3840 x 2160 pixels
Video compression formats: H.264, H.264+, H.265, H.265+
Backup function: Yes
Video capturing speed: 60 fps
Video capturing speed (PAL): 25 fps
Video capturing speed (NTSC): 30 fps
Video loss detection: Yes
Video motion detection: Yes
Channels quantity: 24 channels
Product colour: Black
Playback modes: Event, General, Instant, Smart, Tag
Operating system software: Embedded LINUX
Video output – digital: HDMI
Audio output channels: 1.0 channels
Maximum frame rate: 60 fps
Network connection type: RJ-45
USB connectivity: Yes
Multi-display supported: Yes
Multi-display modes: 1, 4, 8, 9, 16
Bit rate: 6144 Kbit/s
Rack capacity: 1U
Certification: CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 FCC: Part 15 Subpart B
Ports & interfaces
Video input channels: 16 channels
BNC input ports: 16
HDMI ports quantity: 1
VGA (D-Sub) output ports: 1
Ports & interfaces
Audio output: RCA
Audio (L/R) out: 1
Network
Ethernet LAN connection: Yes
Ethernet interface type: Gigabit Ethernet
Ethernet LAN (RJ-45) ports: 1
Hard drive
Hard drive interface: SATA
Maximum hard drive: 16 TB
Processor
Built-in processor: Yes
Power
Power supply type: DC
DC voltage: 12 V
Power consumption (typical): 12 W
Weight & dimensions
Width: 260 mm
Depth: 231,4 mm
Height: 47,6 mm
Weight: 930 g
