Camera
- Image Sensor: 1/3”4Megapixel progressive CMOS
- Max. Resolution: 2688 (H) ×1520 (V)
- ROM: 128 MB
- RAM: 512 MB
- Scanning System: Progressive
- Electronic Shutter Speed: Auto/Manual 1/3 s–1/100000 s
- Min. Illumination: 0.005 Lux@F1.6 (Color, 30IRE)
0.0005 Lux@F1.6 (B/W, 30IRE)
0 Lux (Illuminator on) - S/N Ratio: > 56 dB
- Illumination Distance: 50 m (164.0 ft)
- Illuminator On/Off Control: Auto/Manual
- Illuminator Number: 1 (IR LED)
- Pan/Tilt/Rotation Range: Pan: 0°–360°; Tilt: 0°–90°; Rotation: 0°–360°
Lens
- Lens Type: Fixed-focal
- Mount Type: M12
- Focal Length: 3.6 mm
- Max. Aperture: F1.6
- Field of View: 3.6 mm: Horizontal:84°; vertical: 45° ; diagonal: 100°
- Iris Type: Fixed
- Close Focus Distance: 3.6 mm: 1.6 m (5.3 ft)
DORI Distance
- Lens: 3.6mm
- Detect: 80.0 m (262.5 ft)
- Observe: 32.0 m (105.0 ft)
- Recognize: 16.0 m (52.5 ft)
- Identify: 8.0 m (26.3 ft)
Professional, Intelligent
- Perimeter Protection: Tripwire; intrusion (Recognition of human and vehicle)
- Intelligent Search: Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Video
- Video Compression: H.265; H.264; H.264H; H.264B; MJPEG(only supported by sub stream)
- Smart Codec: Smart H.265+/ Smart H.264+
- Video Frame Rate: Main stream (2688 × 1520@1–25/30 fps)
sub stream (704 × 576@1–25 fps/704 × 480@1–30 fps)
third stream (1280 × 720@1–25/30 fps) - Stream Capability: 3 streams
- Resolution: 4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 ×1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704× 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352× 240)
- Bit Rate Control: CBR/VBR
- Video Bit Rate: H.264: 3 Kbps–8192 Kbps
H.265: 3 Kbps–8192 Kbps - Day/Night: Auto(ICR)/Color/B/W
- BLC: Yes
- HLC: Yes
- WDR: 120 dB
- White Balance: Auto/natural/street lamp/outdoor/manual/regional custom
- Gain Control: Auto/Manual
- Noise Reduction: 3D DNR
- Motion Detection: OFF/ON (4 areas, rectangular)
- Region of Interest(RoI): Yes (4 areas)
- Smart Illumination: Yes
- Image Rotation: 0°/90°/180°/270° (Support 90°/270° with 1920 × 1080 resolution and lower.)
- Mirror: Yes
- Privacy Masking: 4 areas
Audio
- Built-in MIC: Yes
- Audio Compression: G.711a; G.711Mu; G726
Alarm
- Alarm Event: No SD card; SD card full; SD card error; less service time of SD card (smart card supports); network disconnection; IP conflict; illegal access; voltage detection; security exception; motion detection; video tampering; scene changing; input abnormal; intensity change; tripwire; intrusion; SMD
Network
- Network: RJ-45 (10/100 Base-T)
- SDK and API: Yes
- Protocol: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP
- Cyber Security: Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
- Interoperability: ONVIF(Profile S/Profile G/Profile T);CGI;P2P;Milestone; Genetec
- Scene Self-adaptation (SSA): Yes
- User/Host: 20 (Total bandwidth: 64 M)
- Storage FTP; SFTP; Micro SD Card (support max. 256 G); NAS
- Browser: IE: IE8, IE9, IE11
Chrome
Firefox - Management Software: Smart PSS, DSS, DMSS
- Mobile Phone: IOS; Android
Certification
- Certifications: CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive
2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Port
- Audio Input: 1-channel (RCA port)
- Audio Output: 1-channel (RCA port)
- Alarm Input: 1 channel in : 5mA 3V–5V DC
- Alarm Output: 1 channel out: 300mA 12V DC
Power
- Power Supply: 12V DC/PoE (802.3af)
- Power Consumption: <5.4W
Environment
- Operating Conditions: -40°C to +60°C (-40°F to +140°F)/less than 95%
- Storage Conditions: -40°C to +60°C (-40°F to +140°F)
- Protection Grade: IP67
Structure
- Casing: Metal
- Dimensions: 192.7 mm × 70.5 mm × 66.4 mm (7.6”×2.8”×2.6”) (L × W × H)
- Net Weight: 590 g (1.3lb)
- Gross Weight: 780 g (1.7lb)
