Model Number: MCB-NR200P-WGNN-S00
Series: MasterBox Series
Size: Mini ITX
Available Color(s): White
Materials: Steel, Plastic, Mesh, Tempered Glass
Dimensions (L x W x H): 376 x 185 x 292mm incl. Protrusions, 360 x 185 x 274mm excl. Protrusions
Volume (exlc. Protrusions): 18.25L
Motherboard Support: Mini DTX, Mini ITX, Max MB size: 244 x 226mm (L x H)
Expansion Slots: 3
5.25″ Drive Bays: 0
3.5″ Drive Bays: 1 (Max. 2)
2.5″ / 3.5″ Drive Bays (combo): 1
2.5″ Drive Bays: 2 (Max. 3)
I/O Panel: 2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic)
Pre-installed Fans – Top: 2x 120mm 650-1800RPM PWM (SickleFlow)
Pre-installed Fans – Front: N/A
Pre-installed Fans – Rear: N/A
Pre-installed Fans – Bottom: N/A
Fan Support – Top: 2x 120mm
Fan Support – Rear: 1x 92mm
Fan Support – Bottom: 2x 120mm (recommended slim fans for GPUs wider than 2.5 PCI slots)
Fan Support – Side: 2x 120/140mm
Radiator Support – Top: N/A
Radiator Support – Rear: 92mm (not compatible with vertical GPU installation)
Radiator Support – Bottom: 120mm, 240mm, (recommended for custom loops only)
Radiator Support – Side: 120mm, 140mm, 240mm, 280mm, (max width 141mm, not compatible with vertical GPU installation)
Clearance – CPU Cooler: 76mm (GPU in vertical position), 153mm (tempered glass side panel), 155mm (vented steel side panel)
Clearance – PSU: 130mm
Clearance – GFX: L: 330mm (incl. power connector), H: 156mm (incl. power connector), W: 60mm (triple slot)
Dust Filters: Top, Bottom, Left side, Right side
Power Supply Support: SFX, SFX-L
Warranty: 2 years
Weight: 5.1 kg
Accessories: 1x PCIe 3.0 x16 riser cable
Note
Single slot water-cooler GPUs or vertically mounted GPUs are recommended when using bottom radiator position, This product is only compatible for devices that support the PCI-E 3.0 specification. If you use this product with a motherboard that supports PCI-E 4.0, please enter into BIOS option and select PCI-E 3.0 before installation.
