- Converts VGA signals to HDMI output
- Scaler – a premium scaling engine that converts various input video resolutions into the display’s native resolution, while adjusts picture ratio automatically for maximum viewing comfort
- Features a superior de-interlacer function for smooth video playback quality
- Supports analog / digital audio
| Video Output | |
| Interfaces | 1 x HDMI Type A Female (Black) |
| Impedance | 100 Ω |
| Video | |
| Max. Pixel Clock | 165 MHz |
| Max. Resolution | Up to 1080p |
| Scaler Resolutions | 640×480; 800×600; 1024×768; 1280×1024; 1360×768; 1400×1050; 1600×1200; 1440×900; 1680×1050; 1920×1080; 1920×1200; 720p; 1080p |
| Audio | |
| Input | Analog: 1 x Mini Stereo Jack Female (Black) Digital: 1 x RCA (Yellow) |
| Connectors | |
| Power | 1 x DC Jack |
| Power Consumption | DC5V:1.56WBTU |
