Asus SimPro Dock 2 USB-C Docking Station

ASUS SimPro Dock 2 90NX0460-P00150

Connectivity technology: Wired, Host interface: Thunderbolt 3. Ethernet LAN data rates: 10,100,1000 Mbit/s. Product colour: Black, Blue, Maximum digital resolution: 7680 x 4320 pixels, Maximum analog resolution: 1920 x 1080 pixels. Power source type: DC. Width: 40.6 mm, Depth: 99 mm, Height: 161.5 mm

Your one-stop connection station

ASUS SimPro Dock 2 is a sleek, compact one-stop dock that streamlines laptop connectivity. Attach your laptop via a single cable and it’s powered, connected to your network and peripherals, and is primed for multitasking across up to four monitors1 — including an up to 8K display2. It also has an integrated smart card reader for a diverse array of business. Simply, SimPro Dock 2 keeps your desk neat, tidy and organised while setting you up for work in the blink of an eye.3,4

• – One cable, unlimited possibilities​: A total of 5 USB ports, including Thunderbolt 3, Built-in smart card reader for diverse business use​, RJ45 with MAC address pass-through, remote port-disablement and Wake-on-LAN​, Supports up to 6A of power throughput for rapid charging​
• – Slim and compact foot print, occupying barely more space than a smartphone​
• – Seamless sync with your laptop​: Power button to turn on/off laptop​, and LED light to sync laptop power status​

Ports & interfaces
Connectivity technology: Wired
Host interface: Thunderbolt 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
HDMI ports quantity: 1
HDMI version: 2.0
VGA (D-Sub) ports quantity: 1
DisplayPorts quantity: 2
DisplayPort version: 1.4
Thunderbolt 3 ports quantity: 1
Combo headphone/mic port:Yes
DC-in jack: Yes

Network
Ethernet LAN connection: Yes
Ethernet LAN (RJ-45) ports: 1
Ethernet LAN data rates:10, 100, 1000 Mbit/s

Performance
Resolution (maximum digital): 7680 x 4320 pixels
Resolution (maximum analog): 1920 x 1080 pixels
Cable lock slot: Yes
Cable lock slot type: Kensington
Product colour: Black, Blue
On/off switch: Yes
Charging function: Yes
