excerpt: Aruba Instant On AP12 Indoor Access Points deliver affordable, business-grade Wave 2 802.11ac Wi-Fi for low to medium-density small business environments. Business-grade capabilities are designed to meet the mobile, IoT and security needs of small boutiques, tech-start-ups, and retailers at an attractive price point.
wpid: 470962
product_brand:
  - HP
product_type:
  - simple
product_visibility:
  - featured
  - outofstock
product_cat:
  - Access Points
  - Networking
featured_image: "https://tech.co.za/wp-content/uploads/2023/06/R2X01A.png"
---

**Certifications**UL 2043 plenum rating
EN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments)
Wi-Fi Alliance certified (WFA) 802.11ac with Wave 2 (Wi-Fi 5), WPA2, WPA3, Enhanced Open (OWE)

**Input voltage**Power over Ethernet (POE): 802.3af (class 3)
DC power (12V)
Note: Power sources are sold separately

**Wi-Fi antenna**Integrated downtilt omni-directional antennas with maximum individual antenna gain of 3.9dBi in 2.4GHz and 5.4dBi in 5GHz

**Connectivity, standard**IEEE 802.11ac, 802.11n

**Ports**(1) uplink Gigabit Ethernet port, with POE-in support (802.3af)

**Mounting**The access point ships with a (black) mount clip to attach to suspended ceiling rails, and a (white) mount clip to attach to solid surfaces (wall/ceiling).

**Radio coverage**Dual Radio for simultaneous dual-band operation
5 GHz 802.11ac 3×3 MIMO for up to 1,300 Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5)
2.4 GHz 802.11n 2×2 MIMO for up to 300 Mbps wireless data rate (Wi-Fi 4)
