Power consumptionMax Power (w/o PoE): 45W
Max Power (w/ PoE): 480W
Input voltage100-127 VAC / 200-240 VAC
Ports48x ports 10/100/1000BASE-T ports 4x 1G SFP ports
Latency1 Gbps: 1.9 μSec
Routing capabilitiesStatic
Switching capacity104 Gbps
Throughput77.3 Mpps
Memory and processorDual Core ARM Cortex A9 @ 1016 Mhz 8 GB DDR3, maximum, depending on model 16 GB eMMC
PoE capability370W Class 4 PoE/PoE+
Operating temperature32°F to 113°F (0°C to 45°C) up to 5000 ft (1.5 km)
derate -1°C for every 1000 ft (305 m) from 5000 ft
(1.5 km) to 10000 ft (3.0 km)
