Management features
Switch type: Managed
Quality of Service (QoS) support: Yes
Web-based management: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
10G support: Yes
Copper ethernet: 10BASE-T, 100BASE-TX, 1000BASE-T
IP routing: Yes
Full duplex: Yes
Spanning tree protocol: Yes
Auto-sensing: Yes
Auto MDI/MDI-X: Yes
Flow control support: Yes
Rate limiting: Yes
Link aggregation: Yes
VLAN support: Yes
Data transmission
Switching capacity: 320 Gbit/s
Throughput: 112 Mpps
MAC address table: 32768 entries
Latency (1 Gbps): 3.1 µs
Latency (10 Gbps): 3.4 µs
Packet buffer memory: 12.38 MB
Security
DHCP features: DHCP server
Access Control List (ACL): Yes
IGMP snooping: Yes
Authentication: MAC-based authentication, Web-based authentication
SSH/SSL support: Yes
Security algorithms: SNMP
Multicast features
Multicast support: Yes
Design
Rack mounting: Yes
Stackable: Yes
Form factor: 1U
Performance
Built-in processor: Yes
Processor frequency: 1016 MHz
Memory type: DDR3-SDRAM
Internal memory: 1024 MB
Flash memory: 4096 MB
Power
Power supply included: Yes
AC input voltage: 100 – 240 V
AC input frequency: 50 – 60 Hz
Power consumption (typical): 513 W
