Specifications
| Battery type | Lead-acid battery |
| Extended runtime | 0 |
| Number of battery filled slots | 0 |
| Number of battery free slots | 0 |
| Battery recharge time | 3 h |
| Number of battery replacement quantity | 1 |
| Replacement battery | APCRBC124 |
| Battery charger power | 72 W rated |
| Physical | |
| Number of rack unit | 2U |
| Number of cables | 1 |
| Colour | Black |
| Height | 8.6 cm |
| Width | 43.2 cm |
| Depth | 40.6 cm |
| Net weight | 20.52 kg |
| Mounting location | Front |
| Mounting preference | Lower |
| Mounting mode | Rack-mounted |
| Two post mountable | 1 |
| USB compatible | Yes |
| Input | |
| Main Input Voltage | 230 V |
| Other Input Voltage | 220 V 240 V |
| Input Connection Type | IEC 320 C14 |
| Input voltage limits | 170…300 V adjustable 180…287 V |
| Network frequency | 50/60 Hz +/- 3 Hz auto-sensing |
| Output | |
| Main Output Voltage | 230 V |
| Other Output Voltage | 220 V 240 V |
| Rated power in W | 600 W |
| rated power in VA | 1000 VA |
| output connection type | 4 IEC 320 C13 2 IEC Jumpers |
| Harmonic distortion | Less than 5 % |
| Maximum configurable power in VA | 1000 VA |
| Maximum configurable power in W | 600 W |
| Transfer time | 6 ms typical : 10 ms maximum |
| UPS type | Line interactive |
| Wave type | Sine wave |
| Output frequency | 50/60 Hz +/- 3 Hz sync to mains |
| More info: | https://www.se.com/za/en/product/SMC1000I-2UC/apc-smartups-c-line-interactive-1000va-rackmount-2u-230v-4x-iec-c13-outlets-smartconnect-port-usb-and-serial-communication-avr-graphic-lcd/ |
