| Main | |
| Main Input Voltage | 400 V 3 phases |
| Product or component type | Uninterruptible power supply (UPS) |
| Other Input Voltage | 380 V 415 V |
| Output voltage | 400 V 3 phases |
| Other Output Voltage | 380 V 415 V |
| Rated power in W | 10 kW |
| Rated power in VA | 10 kVA |
| Provided equipment | Dust filter Installation guide |
| Range of product | Easy UPS 3S |
| Batteries & Runtime | |
| Efficiency | View Efficiency Graph |
| Battery type | VRLA |
| Battery voltage | 240 V |
| Maximum short-circuit current | 10 kA |
| Number of battery filled slots | 1 |
| Number of battery free slots | 2 |
| Physical | |
| Colour | White (RAL 9003) |
| Height | 140 cm |
| Width | 38 cm |
| Depth | 92.8 cm |
| Net weight | 112 kg |
| Input | |
| Maximum input current | 18 A |
| Input harmonic distortion | Less than 3 % for full load |
| Load power factor | 0.9 leading to 0.9 lagging |
| Input Power Factor at Full Load | 0.99 |
| Input voltage limits | 304…477 V |
| Network frequency | 45…65 Hz |
| Output | |
| Maximum configurable power in VA | 10 kVA |
| Maximum configurable power in W | 10 kW |
| Output frequency | 50 Hz sync to mains 60 Hz sync to mains |
| Harmonic distortion | Less than 3 % |
| Output harmonic distortion | < 3% linear load |
| Output voltage tolerance | #ERROR! |
| UPS type | Double conversion online |
| More info: | https://www.se.com/za/en/product/E3SUPS10KHB1/easy-ups-3s-10-kva-400v-33-ups-1-internal-7ah-modular-battery-string-expandable-to-3/ |
Warning:
Charging and discharging a battery multiple times a day will significantly deteriorate its performance. Please note the limitations of each battery technology:
- Lead-acid batteries can only be discharged up to 50% before irreversible damage occurs.
- Gel lead-batteries can often be discharged up to 70% before irreversible damage occurs.
- Lithium batteries can be fully discharged if they are protected by a Battery Management System.
Due to the above limitations, loss of battery capacity is not covered under warranty.
