Mechanical
Box dimensions: 330 x 330 x 340 mm (13 x 13 x 13.4″)
Box weight: 12 kg (26.5 lb)
Cable length: 305 m (1,000 ft)
Cable color: Black
Cable type: CAT5e, shielded
UV resistance: ASTM G 151/154
Ethernet support: Up to 1 Gbps
Conductor wire gauge: 24 AWG
Conductor: Solid bare copper
Conductor diameter: 0.500 ± 0.005 mm
Insulation type: Solid polyethylene
Insulation thickness: Avg. 0.26 mm
Min. 0.25 mm
Insulation diameter: 1.04 ± 0.03 mm
Separation (Polyester wrapping): Thick: 0.025 mm
Extent: 20 mm
Anti-crosstalk divider: None
Cable shield (Aluminum foil): Thick: 0.060 mm
Extent: 18 mm
ESD drain wire: 0.4 CCS
Rip cord: Yes
Jacket material: Polyethylene
Jacket thickness: Avg. 0.50 mm
Min. 0.46 mm
Jacket outer diameter: 6.0 ± 0.30 mm
Jacket color: Black
Storage temperature: -30 to 75° C (-22 to 167° F)
Installation temperature: -20 to 60° C (-4 to 140° F)
Ambient operating temperature: -40 to 80° C (-40 to 176° F)
Standards: ANSI/TIA-568-C.2 (2009)
ISO/IEC 11801 (Edition 2.2)
