- Eight 10/100/1000Mbps RJ45 ports
- Equipped with four 802.3af/at PoE+ ports with up to 30W for each port, data and power can be transferred on one single cable
- Supports PoE power up to 64W for all PoE ports
- Provides network monitoring, traffic prioritization, VLAN features, and PoE Auto Recovery
- Simple network set-up on top of plug-and-play connectivity
- Web-based user interface and Easy Smart Configuration Utility simplify configuration
HARDWARE FEATURES
Standards and Protocols:
– IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af,
– IEEE 802.3x, IEEE 802.1q, IEEE 802.1p, IEEE 802.3at
Interface:
– Eight 10/100/1000Mbps RJ45 Ports
– AUTO Negotiation/AUTO MDI/MDIX
Network Media:
– 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
– 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
– 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity: Fanless
Power Supply: External Power Adapter (Output: 53.5 VDC/1.31 A)
PoE Ports (RJ45):
– Standard: 802.3 af/at compliant
– PoE Ports: Port 1- Port 4
– PoE Power Budget: 64W
Dimensions ( W x D x H ): 6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm)
Max Power Consumption:
– 5.41 W (220V/50Hz with no PD connected)
– 74.27 W (220V/50Hz with 64 W PD connected)
Max Heat Dissipation:
– 18.45 BTU/h (with no PD connected)
– 253.26 BTU/h (with 64 W PD connected)
