- 62 W PoE Budget: 4× 802.3at/af-compliant PoE+ ports with a total power supply of 62 W*.
- Full Gigabit Ports: 4× gigabit PoE+ ports and 4× gigabit non-PoE ports provide high-speed connections.
- Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)**, Centralized Cloud Management, and Intelligent Monitoring.
- Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
- Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
- Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
HARDWARE FEATURES
Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
Interface:
– 8× 10/100/1000 Mbps RJ45 Ports (Ports 1–4 Support 802.3at/af PoE+)
– Auto-Negotiation/Auto MDI/MDIX
Network Media :
– 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
– 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)
Fan Quantity: Fanless
Power Supply: External Power Adapter (Output: 53.5 VDC/ 1.31 A)
Power Consumption:
– 7.9 W (220 V/50 Hz) (no PD connected)
– 79.2 W (220 V/50 Hz) (with 62 W PD connected)
PoE Ports (RJ45):
– Standard: 802.3af/at compliant
– PoE Ports: 4 Ports
– Power Supply: 62 W*
Dimensions ( W x D x H ): 8.2 x 4.9 x 1.0 in (209 x 126 x 26mm)
Max Power Consumption:
– V1: 69.7 W (220 V/50 Hz) (with 62 W PD connected); 7.9 W (220 V/50 Hz) (no PD connected)
– V2: 73.8 W (220 V/50 Hz) (with 62 W PD connected)
– V3: 77.3 W (110 V/60 Hz) (with 62 W PD connected)
Max Heat Dissipation:
– V1: 237.82 BTU/hr (220 V/50 Hz) (with 62 W PD connected); 26.95 BTU/hr (220 V/50 Hz) (no PD connected)
– V2: 251.84 BTU/hr (220 V/50 Hz) (with 62 W PD connected)
– V3: 263.6 BTU/hr (110 V/60 Hz) (with 62 W PD connected)
