Features
• Pure sine wave output
• 2000 cycles lifePO4 battery
• Mains supply mode, Battery mode
• 5V DC USB 2.0 ports
• 12V DC output ports
• MPPT solar charge controller
• Over charge protection as well as over discharge protection
• Intelligent exhaust fan
Inverter Specifications
Rated Power: 2 000VA / 2 000W
BATTERY
Battery Voltage: 25.6V DC
Battery capacity: 1X 100Ah
Battery cycle life: 2 000 Cycles @ DOD 80%
SOLAR CHARGER
Solar Charger Type: MPPT
Maximum PV Array Power: 840W
Number of MPPTs: 1
MPPT Range @ Operating Voltage: 35 – 100V DC
Maximum Solar Current Charger: 30A (Max)
Floating Charge Voltage: 28.4V DC
DC OUTPUT
Low Voltage recovery: 26.8V DC
Low Voltage Protection: 22.4V DC
5V DC USB Output: 2 Pcs 5V DC, USB 2.0, Max 2A
12V DC Output Ports: 2 Pcs Max 2A
INPUT
Voltage range: 170 – 275V
Mains charging current: 10A
Frequency Range: 45-65Hz
OUTPUT
Voltage: 230V AC
Frequency: 50/60Hz
Output wave form: Pure Sine Wave
