Series: Aruba AP-535
AP type: Indoor, dual radio, 5GHz and 2.4GHz 802.11ax
4×4 MIMO
5GHz radio: Four spatial stream Single User (SU) MIMO for up to 2.4Gbps wireless data rate with individual 4SS
HE80 (or 2SS HE160) 802.11ax client devices, or with four
1SS or two 2SS HE80 802.11ax MU-MIMO capable client
devices simultaneously
2.4GHz radio: Four spatial stream Single User (SU) MIMO for up to 1,147Mbps (574Mbps) wireless data rate with
individual 4SS HE40 (HE20) 802.11ax client devices or with
two 2SS HE40 (HE20) 802.11ax MU-MIMO capable client
devices simultaneously
Antenna: 4 integrated dual-band downtilt omnidirectional antennas for 4×4 MIMO with peak antenna
gain of 3.5dBi in 2.4GHz and 5.4dBi in 5GHz.
Supported data rates(Mbps)

- 802.11b: 1, 2, 5.5, 11
- 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
- 802.11n: 6.5 to 600 (MCS0 to MCS31, HT20 to HT40), 800 with 256-QAM
- 802.11ac: 6.5 to 1,733 (MCS0 to MCS9, NSS = 1 to 4, VHT20 to VHT160), 2,166 with 1024-QAM
- 802.11ax (2.4GHz): 3.6 to 1,147 (MCS0 to MCS11, NSS = 1 to 4, HE20 to HE40)
- 802.11ax (5GHz): 3.6 to 2,402 (MCS0 to MCS11, NSS = 1 to 4, HE20 to HE160)
