PoE Power Supply
- PoE Standard : IEEE 802.3af, IEEE 802.3at
- PoE Power Pin
- End-span: 1/2(-), 3/6(+)
- Mid-span: 4/5(+), 7/8(-)
- 8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
- PoE Port : PoE: Ports 1 to 8
- Max. Port Power : Port 1 to 8: 30 W
- PoE Power Budget : 110 W
Network Parameters
- Port Number : 8 × gigabit PoE port, and 2 × gigabit fiber optical port
- Port Type : RJ45 port, full duplex, MDI/MDI-X adaptive
- Standard : IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, and IEEE 802.3z
- Forwarding Mode
- Store-and-forward switching
- Working Mode
- Standard mode (default)
- Extend mode
- MAC Address Table : 8 K
- Switching Capacity : 20 Gbps
- Packet Forwarding Rate : 14.88 Mpps
- Internal Cache : 4.1 Mbits
Software Function
- Device Maintenance : Remote upgrade, default parameters recovery, logs viewing, basic network
parameters configuration, import and export configuration, time sync - Port Configuration :
- Port rate configuration, flow control, and ports enabling
- Long Range : Up to 300 m transmission
- PoE Configuration
- PoE watchdog: Ports 1 to 8 auto detect and restart the cameras that do not respond.
- PoE enabling: Support
- Port Rate-Limiting : Rate-limiting for ingress and egress ports
- Storm Control : Storm control of unknown unicast, multicast and broadcast
- Port Mirroring : Support
- Link Aggregation : Static link aggregation supported
- Port Isolation : Ports in isolation group cannot communicate with each other.
- QoS : WRR and SP scheduling and port priority
- VLAN : 4094 VLANs
- STP : STP and RSTP protocols
- SNMP : SNMPv1 and SNMPv2c supported for obtaining node information of the
system and interfaces - LLDP : LLDP protocol supported for port configuration, global configuration and
neighbor discovery
General
- Shell : Metal material
- Net Weight : 1.21 kg (2.67 lb)
- Gross Weight : 1.3 kg (2.87 lb)
- Dimension (W × H × D) : 217.6 mm × 27.8 mm × 108.55 mm (8.57” × 1.09” × 4.27”)
- Operating Temperature : -10°C to 55°C (14°F to 131°F)
- Storage Temperature : -40°C to 85°C (-40°F to 185°F)
- Operating Humidity : 5% to 95% (no condensation)
- Relative Humidity : 5% to 95% (no condensation)
- Power Supply : 48 VDC, 2.5 A
- Max. Power Consumption : 120 W
- Power Consumption in Idle : 7 W
