Motion Detection 2.0
Human/Vehicle Analysis: Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;
Video and Audio
IP Video Input: 2-ch
Up to 5 MP resolution
Support H.265+/H.265 IP cameras
Analog Video Input: 8-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI Input: 1080p25, 1080p30, 720p25, 720p30
AHD Input: 1080p25, 1080p30, 720p25, 720p30
HDCVI Input: 1080p25, 1080p30, 720p25, 720p30
CVBS Input: Support
HDMI Output: 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
VGA Output: 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Video Output Mode: HDMI/VGA simultaneous output
Audio Input: 8-ch via coaxial cable
Audio Output: 1-ch via HDMI
Synchronous playback: 8-ch
Audio Compression: G.711u
Audio Bitrate: 64 Kbps
Network
Total Bandwidth: 72 Mbps
Incoming bandwidth: 8 Mbps
Remote Connection: 32
Network Protocol: TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP™, HTTPS
Network Interface: 1, RJ45 10/100 Mbps self-adaptive Ethernet interface
Auxiliary Interface
Capacity: Built-in 1024 GB eSSD (960 GB available)
USB Interface: Rear panel: 2 × USB 2.0
