Camera | |
Image Sensor | 1/2.4″ Progressive Scan CMOS |
Max. Resolution | 3200 × 1800 |
Min. Illumination | Color: 0.003 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR |
Shutter Time | 1/3 s to 1/100,000 s |
Day & Night | IR cut filter |
Angle Adjustment | Pan: 0° to 355°,tilt: 0° to 90°,rotate: 0° to 360° |
Lens | |
Lens Type | Varifocal lens, motorized lens, 2.7 to 13.5 mm and 7 to 35 mm optional |
Focal Length & FOV | 7 to 35 mm: horizontal FOV 34.4° to 12.5°, vertical FOV 19° to 7.1°, diagonal FOV 39.8° to 14.3° |
Lens Mount | 2.7 to 13.5 mm: Ø14; 7 to 35 mm: Integrated |
Focus | Auto,Semi-auto,Manual |
Iris Type | Auto-iris |
Aperture | 7 to 35 mm: F1.6 |
DORI | |
DORI | 7 to 35 mm: D: 218 to 580 m, O: 86 to 230 m, R: 43 to 116 m, I: 21 to 58 m |
Illuminator | |
Supplement Light Type | IR |
Supplement Light Range | 7 to 35 mm: up to 80 m |
Smart Supplement Light | Yes |
IR Wavelength | 850 nm |
Video | |
Main Stream | 50 Hz: |
20 fps (3200 × 1800) | |
25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) | |
60 Hz: | |
20 fps (3200 × 1800) | |
30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) | |
Sub-Stream | 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) |
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) | |
Third Stream | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) |
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) | |
Fourth Stream | 50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) |
60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) | |
Video Compression | Main stream: H.265/H.264/H.264+/H.265+, |
Sub-stream: H.265/H.264/MJPEG, | |
Third stream: H.265/H.264, | |
Fourth stream: H.265/H.264/MJPEG |
