General
- Shell Metal material
- Net Weight 2.735 kg (6.03 lb)
- Gross Weight 3.31 kg (7.30 lb)
- Dimensions (W × H × D) 440 mm × 44 mm × 220.8 mm (17.32” × 1.73” × 8.69”)
- Operating Temperature 0 °C to 45 °C (0 °F to 113 °F)
- Storage Temperature -40 °C to 85 °C (-40 °F to 185 °F)
- Operating Humidity 5% to 95% (no condensation)
- Relative Humidity 5% to 95% (no condensation)
- Power Supply 100 to 240 VAC, 50/60 Hz, Max. 4 A
- Installation Mode Rack (equipped with mounting ears)
- Max. Power Consumption 250 W
- Power Consumption In Idle 25 W
- Surge Protection 6 KV surge protection for PoE ports.
Network Parameters
- Ports 16 × Gigabit PoE port,2 × Gigabit fiber optical port
- MAC Address Table 8 K
- Switching Capacity 56 Gbps
- Packet Forwarding Rate 41.66 Mpps
- Internal Cache 4.1 Mbits
PoE Power Supply
- PoE Standard IEEE 802.3af,IEEE 802.3at
- PoE Power Pin End-span: 1/2(+), 3/6(-);
- PoE Port PoE: Ports 1 to 16
- Max. Port Power 30 W
- PoE Power Budget 225 W
Software Function
Long Range
Ports 1 to 16: up to 300 m.
Long range performance may vary depend on camera model or cable condition.
Port Isolation
Ports 1 to 16: port isolation mode to improve network security.
Ports in an isolation group cannot communicate with each other, but they can communicate with ports outside the isolation group.
PoE Watchdog
Ports 1 to 16: auto detect and restart the cameras that do not respond.
Link Aggregation
Link aggregation is used to aggregate multiple physical ports to form a logical port for load balancing, bandwidth expansion, and port protection.
Support static link aggregation.
Support 8 aggregation groups.
QoS
QoS is used to allocate bandwidth to different services so as to provide end-to-end service quality assurance.
Support port-based priority configuration.
Support SP, WRR priority schedule mode.
Loop Prevention
Loop prevention is used to prevent the switching network from forming loops, which will seriously affect network communication. Disabled by default.
Support 802.1D STP.
VLAN
VLAN is used for network scale planning and network health improvement.
Support 802.1Q.
Configurable VLAN ID from 1-4094.
Support Trunk, Access port mode.
Support Max. 4094 VLAN.
HPP
Support one-click activation and remote management via Hik-Partner Pro. Functions supported:
1. Display the port rate.
2. Display the port bandwidth utilization rate.
3. Display topology information.
4. Display the alarm status.
5. Restart ports and devices.
6. Remotely upgrade the device.
System Maintenance
Remote upgrade, default parameters recovery, logs viewing, basic network parameters configuration, import and export configuration, time sync
Port Rate-Limiting
Port rate-limiting is used for port bandwidth adjustment to prevent network congestion.
Storm Control
Storm control is used to prevent switch ports from being blocked by broadcast or multicast storms in the LAN, which may affect network communication.
Support port rate limiting based on broadcast, multicast, and unknown unicast packets.
Approval
EMC
FCC (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011 +A1: 2014, EN 55035: 2017);
IC (ICES-003: Issue 6);
RCM (ASNZS CISPR 32: 2015)
Safety
UL (UL 60950-1);
CB (IEC 60950-1:2005, AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition);
CE-LVD (EN 60950-1: 2006 + A11: 2009 +A1: 2010+A12: 2011+A2: 2013, EN 62368-1: 2014+A11: 2017)
Chemistry
CE-RoHS (201165EU);
WEEE (201219EU);
Reach (Regulation (EC) No.19072006)
