title: Gigabyte Case C301 ATX RGB Case
date: 2024-09-05T09:21:07Z
modified: 2026-05-05T16:46:43Z
permalink: "https://tech.co.za/product/gigabyte-case-c301-atx-rgb-case-2/"
type: product
status: publish
excerpt: GIGABYTE C301 GLASS WHITE V2 Chassis
wpid: 502347
product_brand:
  - Gigabyte
product_type:
  - simple
product_visibility:
  - featured
product_cat:
  - Components
  - Computer Cases
featured_image: "https://tech.co.za/wp-content/uploads/2024/09/gb-c301gw-type-c-v2-0.jpg"
featured_image_alt: Gaming PC case with RGB fans.
---

#### Specifications

- Form Factor: Mid Tower
- M/B Type: mini-ITX / m-ATX / ATX/ E-ATX
- Colour: Black
- Materials: Steel, Plastic, Glass
- Dimensions (HxWxD): 486 x 220 x 473 mm (Within ± 1% error)
- Expansion slots: 7‎
- **Drive Bays**
    - 5.25″: None
    - 3.5“/2.5”: 2‎
    - 2.5″: 2
- **I/O Panel**
    - USB 3.2 Gen2 Type-C x1
    - USB 3.0 x2
    - Audio In & Out (supports HD Audio)
    - LED Switch
- **Pre-installed Fans**
    - Front: 120mm x3 (ARGB & PWM)
    - Rear: 120mm x1 (ARGB & PWM)
    - Fan splitter cable included
- **Radiator Support**
    - Front: 360mm
    - Top: 360mm
    - Rear: 120mm
- Power Supply Type: Standard ATX (Not included)
- **Maximum Compatibility**
    - CPU Height: 170mm
    - GPU Length: 400mm
    - PSU Length: 180mm
- Vertical GPU Mount: Yes (Requires PCIe Riser Cable)
- Dust Filters: Top, Bottom
- RGB Lighting: Yes (Support RGB Fusion)
- Weight: 7.8 Kg
- **Accessories**
    - Manual
    - Accessories kit
