title: Gigabyte C500 Panoramic Stealth ATX Chassis
date: 2026-03-07T13:56:35Z
modified: 2026-05-20T11:05:35Z
permalink: "https://tech.co.za/product/gigabyte-c500-panoramic-stealth-atx-chassis/"
type: product
status: publish
excerpt: "Panoramic Tempered Glass Front and Side Panels\\nOptimized Airflow Design\\nSupport Back-Connect Motherboard Design, Compatible with GIGABYTE Stealth Series"
wpid: 573355
product_brand:
  - Gigabyte
product_type:
  - simple
product_cat:
  - Components
  - Computer Cases
featured_image: "https://tech.co.za/wp-content/uploads/2026/03/GB-C500P-STa.jpg"
---

| Case Form Factor | Mid Tower |
| --- | --- |
| M/B Type | Mini ITX / Micro ATX / ATX |
| Color | Black |
| Materials | Steel, Plastic, Glass |
| Dimensions | H=501 W=235 D=430 mm (Within ± 1% error) |
| Expansion Slots | 7 |
| 5.25″ Drive Bays | None |
| 3.5″ Drive Support | 2 |
| 2.5″ Drive Support | 1 + 2 (Replace from 3.5″) |
| I/O Panel | USB 3.2 Gen2 Type-C x1 USB 3.0 x2 Reset Button Audio In & Out (supports HD Audio) |
| Pre-installed Fans | Side : 120mm x3 (ARGB) \*Reverse Blade Fan Rear : 120mm x1 (ARGB) |
| Fan Support | Top : 120mm\*3 / 140mm\*2 Bottom : 120mm\*3 Side : 120mm \*3 Rear : 120mm\*1 / 140mm \*1 |
| Radiator Support | Top : Max 360mm Side : Max 360mm Rear : Max 140mm |
| Power Supply Type | Standard ATX (Not included) |
| Maximum Compatibility | CPU Height : 176mm GPU Length : 410mm PSU Length : 200mm |
| Vertical GPU Mount | YES (5-slot total clearance ) |
| Dust Filters | Top, Side, Bottom |
| RGB Lighting | Yes (supports RGB Fusion) |
| More info: | [https://www.gigabyte.com/PC-Case/GB-C500P-ST/sp](https://www.gigabyte.com/PC-Case/GB-C500P-ST/sp) |
