Performance
Video input channels: 8 channels
Alarm input channels: 4
Alarm output channels: 2
Maximum resolution: 3840 x 2160 pixels
Supported resolutions: 3840 x 2160, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Bit rate: 20000 Kbit/s
Number of users: 128 user(s)
Two-way talk: Yes
Video motion detection: Yes
Number of motion detection zones: 396
Video loss detection: Yes
On Screen Display (OSD): Yes
Video formats supported: H.264, H.265, M-JPEG, MPEG4
Operating system software: Embedded LINUX
Backup function: Yes
Split screen: Yes
PTZ control: Yes
Snapshot: Yes
Playback modes: Backup selection, Digital zoom, Forward, Full screen, Next camera, Pause, Play, Previous camera, Repeat, Reverse, Shuffle, Speed Adjust, Stop
Playback controls: Yes
Throughput data rate: 320 Mbit/s
Recording modes: Manual, Schedule, Stop
Recording time: 120 min
Hard drive
Included hard drives: 2
Maximum storage capacity: 24 TB
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Power supply PoE: No
Ethernet LAN data rates: 10, 100, 1000 Mbit/s
HDMI output: Yes
HDMI ports quantity: 1
Ports & interfaces
VGA (D-Sub) output ports: 1
USB 2.0 ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
Audio RCA inputs: 1
Audio RCA outputs: 1
RS-232 interface: Yes
Supported network protocols: HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP
Features
Rack mounting: Yes
Rack capacity: 1U
Brand compatibility: Any brand
Compatible products: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek
Processor
Built-in processor: Yes
Processor number of cores: 4
Weight & dimensions
Width: 375 mm
Depth: 282 mm
Height: 56 mm
Weight: 1,6 kg
