Management features
Switch type: Managed
Switch layer: L2
Quality of Service (QoS) support: Yes
Web-based management: Yes
ARP inspection: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity: 4
Fiber optic connector: SFP+
Console port: RJ-45
Network
Networking standards: IEEE 802.1AX, IEEE 802.1D, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x
10G support: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supported: Cat5, Cat5e
Port mirroring: Yes
Full duplex: Yes
Flow control support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Auto MDI/MDI-X: Yes
Spanning tree protocol: Yes
Head-of-line (HOL) blocking: Yes
Auto-negotiation: Yes
VLAN support: Yes
Virtual LAN features: Private VLAN, Voice VLAN, Tagged VLAN, MAC address-based VLAN, Port-based VLAN
Number of VLANs: 4094
Data transmission
Switching capacity: 128 Gbit/s
Forwarding rate: 95.24 Mpps
MAC address table: 16000 entries
Store-and-forward: Yes
Jumbo frames support: Yes
Jumbo frames: 9216
Packet buffer memory: 1.5 MB
Power
Redundant power supply (RPS) support: Yes
AC input voltage: 100 – 240 V
AC input frequency: 50 – 60 Hz
Power consumption (max): 22.1 W
Surge protection voltage: 6 kV
Weight & dimensions
Width: 440 mm
Depth: 210 mm
Height: 44 mm
Weight: 2 kg
