Streamline Your Build Experience
The pre-installed, pre-routed power supply and CPU-cooler allows for ease of building and optimal cable & tubing management. Install a motherboard, HDDs and finish off with a GPU: no hassle, no routing. Stow away excess cables and you’re good to go.
Materials – Exterior: SGCC Steel, Mesh, ABS Plastic
Materials – Left Side Panel: Tempered Glass x1, Steel x1
Dimensions (L x W x H): 377 x 185 x 292mm (incl. Protrusions), 361 x 185 x 274mm (excl. Protrusions)
Volume: 18.30L
Motherboard Support: Mini-ITX, Max. size: 170 x 180mm
Expansion Slots: 3
Drive Bays – 5.25″ ODD: 0
Drive Bays – 3.5″ HDD: 1 (Max. 2)
Drive Bays – 3.5″ / 2.5″ Combo: 1
Drive Bays – 2.5″ SSD: 2 (Max. 3)
I/O Panel: 2 x USB 3.2 Gen 1 (USB 3.0), 1x 3.5mm Headset Jack (Audio + Mic)
Included Accessories: 1x MasterAccessory Riser Cable PCIe 4.0 x16 – 35mm
Included CPU Cooling Solution: 280mm radiator, 2 x 140mm SickleFlow PWM, Gen 3 Cooler Master Pump / CPU Block
Included Power Supply Unit: V850 SFX GOLD 850 Watt
Fan Support – Top: 2 x 120mm / 2 x 140mm
Fan Support – Bottom: 1 x 120mm (max 15mm, with 3.5″ HDD at the bottom), 2 x 120mm (max 15mm, w/o 3.5″ HDD at the bottom)
Radiator Support – Top: 240mm / 280mm
Clearances – CPU Cooler: 67mm
Clearances – Power Supply: 130mm
Clearances – Graphics Card: L: 336mm (incl. power connector)
, H: 160mm (incl. power connector)
, W: 75mm (triple slot)
Dust Filters: Bottom, Left, Right, Top Panels
Power Supply Support: SFX, SFX-L
